From bonefish to chinook, tarpon to trout, the properties of our premium cork drag give you the stopping power you need with the smoothness you crave for consistent fish fighting pressure fish after fish, year after year. On top of that, our ingeniously simple system virtually eliminates the trip-ruining failures of canister-type drag systems.
The LX’s large arbor spool increases your retrieval rate so that when that torpedo runs right at you, you’ve got the pick up to stay on it. At the same time, spey anglers have all the capacity they need in the 4.0 & 4.5 inch model to tackle the big rivers where the chrome and the king reign.
Right or left handed… It doesn’t matter. With a simple procedure, you can reel your reel your way.
| Model | LX3.4 | LX3.6 | LX3.8 | LX4 | LX4.5 |
| Line Wt. | Â 6-7 | 7-8 | 8-9 | 9-10 | 11-13 |
| Diam. | Â 3.4 in | 3.6 in | 3.8 in | 4.1 in | 4.5 in |
| Width | 0.79 in | 0.79 in | 0.91 in | 1.0 in | 1.12 in |
| Weight | Â 5.9 oz | 6.2 oz | 7.8 oz | 8.9 oz | 9.9 oz |
| Capacity* | WF6F + 125 yds 20# | WF7F + 175 yds 20# | WF8F + 200 yds 20# | WF9F + 200 yds 30# | WF10F + 175 yds 30# |
| Construction | CNC machined in Canada 6061-T6 solid billet aluminum | CNC machined in Canada 6061-T6 solid billet aluminum | CNC machined in Canada 6061-T6 solid billet aluminum | CNC machined in Canada 6061-T6 solid billet aluminum | CNC machined in Canada 6061-T6 solid billet aluminum |
| Click-Drag Mechanism | CNC machined in Canada 7075-T6 hardcoat aluminum clutch with graphite impregnated cork and a titanium clicker. | CNC machined in Canada 7075-T6 hardcoat aluminum clutch with graphite impregnated cork and a titanium clicker. | CNC machined in Canada 7075-T6 hardcoat aluminum clutch with graphite impregnated cork and a titanium clicker. | CNC machined in Canada 7075-T6 hardcoat aluminum clutch with graphite impregnated cork and a titanium clicker. | CNC machined in Canada 7075-T6 hardcoat aluminum clutch with graphite impregnated cork and a titanium clicker. |
| Drag Adjustment | Drag adjustment knob and coil spring | Drag adjustment knob and coil spring | Drag adjustment knob and coil spring | Drag adjustment knob and coil spring | Drag adjustment knob and coil spring |
| Spindle | CNC machined in Canada 316 bar stock stainless steel | CNC machined in Canada 316 bar stock stainless steel | CNC machined in Canada 316 bar stock stainless steel | CNC machined in Canada 316 bar stock stainless steel | CNC machined in Canada 316 bar stock stainless steel |
| Rotation | 3 sealed bearings and a self lubricating Oilite® bearing | 3 sealed bearings and a self lubricating Oilite® bearing | 3 sealed bearings and a self lubricating Oilite® bearing | 3 sealed bearings and a self lubricating Oilite® bearing | 3 sealed bearings and a self lubricating Oilite® bearing |
| Finish | Anodized (All aluminum parts) | Anodized (All aluminum parts) | Anodized (All aluminum parts) | Anodized (All aluminum parts) | Anodized (All aluminum parts) |
| Assembly | All assembled by hand in Canada. | All assembled by hand in Canada. | All assembled by hand in Canada. | All assembled by hand in Canada. | All assembled by hand in Canada. |
